Icom

IC-A120

Key Features VHF Air Band Transceivers High Visibility, Simple Operation Optional Bluetooth ® Headset Connectivity Active Noise Cancelling (ANC) IP54 Dust-Protection and Water Resistance Dualwatch and ON-Hook Scan Functions Side Tone Function Optional…

Brand: Icom
Category: Aviation
Manufacturer: Icom website ↗
Availability: Enquire for lead time

Downloads

IC A120 LTPDF

Technical

Specifications

Frequency range (TX/RX)	118.000–136.992 MHz
Channel spacing	25 kHz/8.33 kHz
Type of emission	6K00A3E, 5K60A3E (FCC/EXP); 6K00A3E (Industry Canada)
Operating temperature range	–30˚C to +60˚C; –22˚F to +140˚F
Frequency stability	±5 ppm (–30˚C to +60˚C)
Antenna connector	SO-239 (50 Ω)
Number of memory channels	200 channels
Power supply requirements	13.75 V/27.5 V DC
Current drain (at 13.75 V) TX	5.0 A max
Current drain (at 13.75 V) RX Stand-by	0.5 A
Current drain (at 13.75 V) RX Max. audio	4.0 A
Dimensions (W×H×D)	161×45×175 mm / 6.34×1.77×6.89 in
Weight	1.5 kg; 3.3 lb
Output power (at 13.75 V)	9.0 W typical; 10.0 W maximum
Spurious emissions	Less than –60 dBc
Modulation	70% to 100%
Microphone impedance	600 Ω
Intermediate frequencies	38.85 MHz/450 kHz (1st/2nd)
Sensitivity (at 6 dB S/N)	Less than 1 μV
Selectivity	8.33 kHz: 2.778/7.37 kHz (6 dB/60 dB); 25 kHz: 8/25 kHz (6 dB/60 dB)
Spurious response rejection	More than 74 dBμ
Audio output power Internal speaker	1.5 W
Audio output power External speaker	10+ W
Audio output power Headphone	100+ mW

Overview

About this product

Top Performance Mobile Airband Radio with Active Noise Cancelling and Bluetooth^® Wireless Connectivity

Other features

A total of 200 memory channels with 12-character channel names
Both 12- and 24- volt systems compatible
8.33 kHz* and 25 kHz channel spacing
36W (P.E.P.) RF output power
Dualwatch and priority scan functions
Power on password protection
PC programming capability
CI-V Commands for external control
VE-PG3 RoIP gateway for interconnect with other radio devices

* Use of 8.33 kHz channel spacing is prohibited in Canada

Supplied Accessories

Hand microphone, HM-216
DC power cable
Mounting bracket kit
Microphone hanger kit
Fuses
